BD14120-1EH-TS
WindGuard (BD) 14
The premier end of our heavy industrial range, the WindGuard 14 series features belt driven fans powered by 5 HP and larger motors, which can repel wind gusts of up to 30 MPH at heights up to 14 ft. high. They are the ultimate in air curtain performance for industrial applications, like warehouses and distribution and transportation centers. Standard color for these industrial models is Titanium Silver and heated options are available.
The Mars Guarantee
Backed by stringent testing, quality control protocols & certified by the toughest accrediting laboratories & agencies. Mars offers one of the most rigorous warranties available anywhere
Model Specs
| MPN | BD14120-1EH-TS |
| Environmental - Max Height (feet) | 16 |
| Insect - Max Height (feet) | 14 |
| Series | BD (WindGuard) Series |
| Heating Mode | Electric |
| Nozzle Width (inches) | 120 |
| Unit Width (inches) | 131 |
| Unit Height (inches) | 28 |
| Wind Stopping Capability (MPH) | 25 |
| Horsepower | 5 |
| Motors | 1 |
| Color | Titanium Silver |
| ETL sanitation certified to ANSI/NSF 37 standards | No |
| Air Flow Certified (AMCA) | No |
| Power, Electric Heat (kW) | 140 |
| Voltage Rating | 460/3/60 |
| Voltage Code | H |
| Air Curtain Air Volume (CFM) | 14650 |
| Amps | 182.5 |
| Uniformity (%) | - |
| dBA | 73 |
| Freight Included | No |
